Intelligent medical

DETAILED

ECG	1. Lead mode : Ⅰ、Ⅱ、Ⅲ、AVR、 AVL、 AVF、 V
	2. Gain : X0.25 、X0.5 、X1 、X2
	3. Heart Rate : 15-300BPM(Adult)15-350BPM(Neonatal) Resolution : 1BPM Accuracy : ±1%
	4. ST measurement Range : -2.0 - +2.0mV Accuracy : ±10%
	5. Pacemaker : Yes
	6. Sweep Speed : 12.5mm/s,25mm/s,50mm/s
	7. Bandwidth :		Diagnostic : 0.05 ~ 130 Hz
			Monitor : 0.5 ~ 40 Hz
			Surgery : 1 ~ 20 Hz
SPO2	1. Measure range : 0-100%
	2. Resolution : 1%
	3. Accuracy : 2% (70-100%)
	4. Pulse Rate : 20-250 BPM
	5. Resolution : 1BPM
	6. Accuracy : ±3BPM
RESP	1. Measure range : 0-150BrPM
	2. Resolution : 1BrPM
	3. Accurac y : ± 2%
TEMP	1. Measure range : 0-50℃
	2. Resolution : 0.1℃
	3. Accuracy : ±0.1℃
NIBP	1. Work Mode : Manual 、 Automatic 、continuous
	2. Unit : mmHg,kPa
	3. Measure range :
		Adult	SYS : 40-280mmHg
			DIA : 10-225mmHg
			MEAN : 20-240mmHg
		Pediatric	SYS : 40-220mmHg
			DIA : 10-160mmHg
			MEAN : 20-170mmHg
		Neonatal	SYS : 40-135mmHg
			DIA : 10-100mmHg
			MEAN : 20-110mmHg
	4. Resolution : 1mmHg
	5. Accuracy : ± 5mmHg



• Manufacturing as well distribution of medical devices for cardiology, patient monitoring, home healthcare , rescue & surgery and veterinary
• All kinds of products can be customized according to customer`s needs.
